SNRG Block™ System 1 and 2

Part #: SNRG Block

The **SNRG Block™** digestion systems are advanced laboratory instruments designed for the **digestion and evaporation of various sample types**, including water, wastewater, soil, and sludge. The system is offered in two versions—**System 1** and **System 2**—with modular compatibility for different tube sizes (15, 50, 100 mL). Equipped with a detachable **7” touchscreen controller** and **remote WiFi access**, this device provides flexible and precise temperature programming, making it ideal for **sample preparation in environmental and analytical labs**.


                                                    High-Temperature Performance

                                                Capable of reaching up to 240°C, suitable for complex digestion processes.


                                                    Smart Touchscreen Control

                                                A detachable 7” magnetic touchscreen display offers direct control and status visualization.


                                                    Remote Operation

                                                Built-in WiFi allows secure remote monitoring, method configuration, and data export via a browser.


                                                    Multi-Tube Compatibility

                                                Supports 15, 50, and 100 mL tubes with interchangeable graphite inserts and racks.


                                                    Accurate Temperature Monitoring

                                                Includes internal and optional external temperature sensors with calibration capabilities for high-accuracy applications.


                                                    Real-Time LED Status Display

                                                LED bars on the sides and front indicate system heating status (blue to red gradient).


                                                    Easy Maintenance

                                                Tool-free insert removal, washable inserts, and minimal component complexity ensure smooth maintenance.

Specification	Value
Models Available	SNRG Block System 1 / System 2
Tube Volume Support	15 mL, 50 mL, 100 mL
Max Temperature	240 °C
Control Interface	7″ detachable touchscreen + remote WiFi
Voltage	115V / 230V
Power	1500W (System 1), 1900W (System 2)
Dimensions (W x D x H)	Sys.1: 43.3×36.7×19.4 cm, Sys.2: 52.8×47.3×19.4 cm
Weight	Sys.1: 17 kg, Sys.2: 24 kg
Ambient Operating Temp	15–40 °C
Humidity Range	30%–80% RH
Connectivity	USB, WiFi (in certified regions)
Compliance	CE, FCC, UL, RoHS
