Oil spectrometer PO300

Part Number: PO300

The PO300 is an advanced rotating-disc electrode (RDE) optical emission spectrometer crafted for fast and accurate elemental analysis of both new and used lubricating, hydraulic, and fuel oils—plus greases and industrial water. It operates under ASTM D6595, ASTM D6728, NB/SH/T0865‑2013, and HB20094.1‑2012 standards. Utilizing a graphite RDE light source and dual-fiber, dual-optical CCD setup, the system delivers full-element profiles in under 30 seconds, with no need for dilution or auxiliary gases .


                                                    Ultra-Fast 30‑Second Analysis

                                                Provides complete multi-element readings in less than half a minute—accelerating decision-making and condition monitoring .


                                                    Comprehensive 24‑Element Detection

                                                Simultaneously analyzes 24 key wear and additive elements (Al, Ba, B, Ca, Cd, Cr, Cu, Pb, Mg, Mn, Mo, Ni, P, Si, Ag, Na, Sn, Ti, V, Zn, Fe, K, Li, Sb), with detection ranges from 0–1000 ppm (19 elements) and 0–6000 ppm (5 elements) .


                                                    High‑Resolution Dual Optics CCD System

                                                Equipped with Paschen–Runge + C-T optical design, 400 mm focal length, dual fiber optic inputs, and constant-temperature control (38 °C ± 0.1 °C), delivering high stability and precise results (< 1 ppm detection limit) .


                                                    Built‑In Graphite Electrode Sharpener & Printer

                                                Automatic electrode sharpening and internal printer streamline maintenance and recording processes—integrated for seamless lab use .


                                                    No Sample Prep, No Cross‑Contamination

                                                Samples are tested directly from the cup without dilution or gases, supported by built-in exhaust to prevent contamination .

Specification	Value
Analysis Time	≤ 30 seconds
Spectral Range	200–800 nm
Optical Focal Length	400 mm
Detector	High-resolution CCD (3648 pixels/channel)
Elements	24 standard (up to 32 optional)
Detection Limit	< 1 ppm
Sample Volume	~2 mL
Temperature-Controlled Optics	Maintains 38 °C ± 0.1 °C for consistent results
Power Supply	AC 220 V, 50/60 Hz
Dimensions (W×D×H)	550 × 330 × 430 mm
